Product Summary
The PD800A-230-30 is an AC-DC front end power module. It offers maximum in designe flexibility, All functions, including filtering, power factor correction, AC/DC conversion as well as monitoring and signal-generation are integrated into the modules. The size and form makes it very simple to use as a basic component for a 3U, 6U or an induvidually built power supply.
Parametrics
PD800A-230-30 absolute maximum ratings: (1)input voltage range: 200-240VAC; (2)nominal output voltage: 30VDC; (3)maximum output current: 24A; (4)output votlage range: 24-32V; (5)efficiency: 90%; (6)input current: 3.8A; (7)power factor: 0.95 min.
Features
PD800A-230-30 features: (1)wide range input 88-265VAC; (2)high efficiency 90% typ; (3)conducted EMC; (4)power factor correction.
Diagrams
 |
