Product Summary
The APDS-9003-021 is a low cost analog-output ambient light photo sensor in miniature chipLED lead-free surface mount package. It consists of a spectrally suited photo sensor, which provides excellent responsivity that is close to the response of the human eyes, as shown in figure 2. The APDS-9003-021 is ideal for applications in which the measurement of ambient light is used to control display backlighting. Mobile appliances such as the mobile phones and PDAs that draw heavy current from display backlighting will benefit from incorporating these photo sensor products in their designs by reducing power consumption significantly. The applications of the APDS-9003-021 are Detection of ambient light to control display backlightings, Automatic Residential and Commercial Lighting Management and Electronic Signs and Signals.
Parametrics
APDS-9003-021 absolute maximum ratings: (1)Storage Temperature TS: -40 to 85℃; (2)Supply Voltage VCC: 0 to 6V; (3)Operating Temperature TA: -40 to 85℃; (4)Supply Voltage VCC: 2.4 to 5.5 V.
Features
APDS-9003-021 features: (1)Excellent responsivity Close responsivity to the human eye; (2)Miniature ChipLed Leadfree surface-mount package: Height – 0.55mm; Width – 1.60mm; Depth – 1.50mm; (3)Low sensitivity variation across various light sources; (4)Operating temperature: -40 to 85℃; (5)Vcc supply 2.4 to 5.5V; (6) ROHS compliant and Lead Free Package.
Diagrams
