Product Summary
The RXM-433-LC-S is a RF receiver ideally suited for volume use in OEM applications such as remote control, security, identification, and periodic data transfer. Housed in a compact surface-mount package, the RXM-433-LC-S transmitter utilizes a highly-optimized SAW architecture to achieve an unmatched blend of performance, size, efficiency, and cost. When paired with a matching RXM-433-LC-S receiver, a highly reliable wireless link is formed, capable of transferring serial data at distances of up to 3,000 feet.
Parametrics
RXM-433-LC-S absolute maximum ratings: (1)Supply Voltage, VCC: -0.3 to +6.0VDC; (2)Any Input or Output, Pin: -0.3 to VCC VDC; (3)Operating Temperature: -30 to +70℃; (4)Storage Temperature: -45 to +85℃.
Features
RXM-433-LC-S features: (1)Low cost; (2)No external RF components required; (3)Ultra-low power consumption; (4)Compact surface-mount package; (5)Stable SAW-based architecture; (6)Supports data rates to 5,000bps; (7)Wide supply range (2.7 to 5.2VDC); (8)Direct serial interface; (9)Low harmonics; (10)No production tuning.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 RXM-433-LC-S |
|
RECEIVER RF 433MHZ SMT |
Data Sheet |
Negotiable |
|
||||||||||||
