Product Summary
The BC213159A20-RK-E4 is a PNP silicon amplifier transistor.
Parametrics
BC213159A20-RK-E4 absolute maximum ratings: (1)Collector–Emitter Voltage VCEO: –30Vdc; (2)Collector–Base Voltage VCBO: –45Vdc; (3)Emitter–Base Voltage VEBO: -5.0 Vdc; (4)Collector Current : 100 mAdc; (5)Total Device Dissipation, PD: 350mW; (6)Operating and Storage Junction Temperature Range, TJ, Tstg: –55to +150℃.
Features
BC213159A20-RK-E4 features: (1)Collector–Emitter Breakdown Voltage, V(BR)CEO: –30Vdc; (2)Collector–Base Breakdown Voltage, V(BR)CBO:–45Vdc; (3)Emitter–Base Breakdown Voltage, V(BR)EBO:–5Vdc; (4)Collector–Emitter Leakage Current, ICBO:–15nAdc; (5)Emitter–Base Leakage Current, IEBO :–15nAdc.
