Product Summary
The AD9066JR is a dual 6-bit ADC that has been optimized for low-cost in-phase and quadrature (I and Q) demodulators. Primary applications include digital direct broadcast satellite applications where broadband quadrature phase shift keying (QPSK) modulation is used. In these receivers the recovered signal is separated into I and Q vector components and digitized. The AD9066JR is suitable for Direct Broadcast Satellite (DBS) Receivers, QAM Demodulators, Wireless LANs, VSAT Receivers.
Parametrics
AD9066JR absolute maximum ratings: (1)ENCODE: –0.5 +VS V; (2)+VS: 7.0 V; (3)INA, INB: –0.5 +VS V; (4)VT: 2.5 +VS V; (5)REF A, REF B: –0.5 +VS V; (6)VB: 0.0 +VS V; (7)D0–D5 Current OUT: 20 mA.
Features
AD9066JR features: (1)Two Matched ADCs on Single Chip; (2)CMOS-Compatible I/O; (3)Low-Power (400 mW) Dissipation; (4)Single +5 V Supply; (5)On-Chip Voltage Reference; (6)Self-Biased for AC-Coupled Inputs; (7)28-Lead SOIC and SSOP Packages.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 AD9066JR-REEL |
Analog Devices Inc |
IC ADC 6BIT DUAL 60MSPS 28-SOIC |
Data Sheet |
Negotiable |
|
||||
|
AD9066JR |
Analog Devices Inc |
IC ADC 6BIT DUAL 60MSPS 28-SOIC |
Data Sheet |
Negotiable |
|
||||
