Product Summary
The SKM150GB173D is an IGBT module. The typical applications of the device are AC inverter drives on mains 575-750VAC, DC bus voltage 750-1200VDC, pubic transport and switching.
Parametrics
SKM150GB173D absolute maximum ratings: (1)VCES: 1700V; (2)IC: 150A; (3)ICRM: 200A; (4)VGES: ±20V; (5)Tvj: -40 to 150℃; (6)Tstg: -40 to 125℃; (7)Visol: 4000V.
Features
SKM150GB173D features: (1)MOS input; (2)N channel, homogeneous Si; (3)low inductance case; (4)very low tail current with low temperature dependence; (5)high short circuit capability self limiting to 6Icnom; (6)latch-up free; (7)fast & soft inverse CAL diodes; (8)isolated copper baseplate using DCB direct copper bonding; (9)large clearance and creepage distance.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 SKM150GB173D |
Other |
|
Data Sheet |
Negotiable |
|
||||
